22988166 Factory Wholesale Air Oil Separator Element Air Compressors Spare Parts Oil Separator Filter for Ingersoll-Rand

22988166 Oil Filter Element for Industrial Air Compressors – Technical Specifications & Maintenance Guide

Product Description

The 22988166 oil filter element is engineered for industrial screw air compressors, serving as a critical safeguard to remove contaminants from lubricating oil. Constructed with multi-layer borosilicate glass fiber media and housed in a corrosion-resistant stainless steel casing, this filter ensures efficient filtration of metal particles, carbon deposits, and sludge, maintaining optimal oil cleanliness and protecting compressor components from premature wear .

Key Features

• High Filtration Efficiency: Removes particles ≥10μm with 99.8% efficiency, reducing oil contamination and extending downstream component lifespan.




• Low Initial Pressure Drop: ≤0.03 MPa, minimizing energy loss and ensuring stable oil flow.




• Wide Temperature Range: Operates effectively between -20°C to +120°C, suitable for harsh industrial environments .




• Durability: Reinforced steel casing resists mechanical stress and chemical degradation.




Usage & Maintenance Guidelines

1. Installation:

   • Shut down the compressor and drain residual pressure.




   • Replace the filter every 1,500–2,000 operating hours or when pressure drop exceeds 0.15 MPa.




   • Use a torque wrench to secure the filter, avoiding over-tightening to prevent seal damage .







2. Routine Checks:

   • Monitor differential pressure gauges weekly.




   • Inspect for leaks, cracks, or gasket deterioration during maintenance intervals.







3. Replacement:

   • Dispose of used filters per environmental regulations (oil-contaminated waste requires special handling).







Consequences of Delayed Replacement

• Reduced Lubrication Efficiency: Contaminated oil accelerates bearing and rotor wear, leading to compressor seizure.




• Increased Energy Costs: Elevated pressure drop forces the compressor to work harder, raising operational expenses by up to 15%.




• System Failures: Unfiltered debris can clog oil passages, causing overheating and potential fire hazards due to friction-induced sparks .




• Downtime & Repairs: Severe contamination may require costly repairs (e.g., $5,000–$10,000 for rotor replacement) and extended production halts.




Summary

The 22988166 oil filter element is a vital component for sustaining compressor performance and longevity. Regular maintenance and timely replacement are essential to mitigate risks of mechanical failure, energy waste, and costly downtime.
