54509500 39890600 Air Compressor Spare Parts Oil and air Separator

54509500 & 39890600 Oil-Gas Separator Filters for Ingersoll Rand M250 Series Compressors

Product Overview

The 54509500 and 39890600 are high-performance oil-gas separator filters designed exclusively for Ingersoll Rand’s M250 series screw air compressors. As critical components of the compressed air system, these filters remove oil mist, aerosols, and solid contaminants from compressed air, ensuring clean, dry air output for downstream equipment while extending compressor lifespan. Manufactured to meet strict industrial standards, they combine advanced filtration technology with durable materials for reliable performance in demanding environments.

Key Technical Specifications

Product Descriptions

54509500 Oil-Gas Separator Filter

The 54509500 is a premium oil-gas separator filter engineered for Ingersoll Rand’s M250 series 40HP screw compressors. It features a multi-layer borosilicate glass fiber filter media that effectively captures oil mist, aerosols, and solid particles as small as 0.1μm, ensuring outlet air meets strict industrial cleanliness standards (≤3ppm oil content). The filter’s compact design (431×444×444mm) and durable construction make it suitable for harsh industrial environments, while its low initial pressure differential (≤0.02MPa) minimizes energy consumption. Regular maintenance (replacement every 3,000–5,200 hours) ensures consistent performance and protects the compressor from oil contamination.

39890600 Oil-Gas Separator Filter

The 39890600 is a high-efficiency oil-gas separator filter designed for Ingersoll Rand’s M250 series 40HP screw compressors. It uses a advanced multi-layer glass fiber media to remove 99.99% of oil mist and aerosols, delivering outlet air with ≤3ppm oil content. The filter’s robust construction and corrosion-resistant materials ensure long-term reliability in demanding applications. With a low initial pressure differential (≤0.02MPa) and a service life of 3,000–5,200 hours, it helps reduce operational costs and extend compressor lifespan. Compatibility with Ingersoll Rand’s M250 series ensures seamless integration and optimal performance.

Applications

Both filters are ideal for use in Ingersoll Rand M250 series compressors, which are widely used in manufacturing, automotive, aerospace, and other industrial sectors where clean, dry compressed air is critical. They are particularly suitable for applications requiring high air quality, such as painting, welding, and precision machining.

Maintenance Guidelines

• Inspection: Check the filter every 500 hours for dirt accumulation and damage.




• Cleaning: Clean the filter housing and components every 1,000 hours using compressed air (≤0.3MPa) to remove loose debris.




• Replacement: Replace the filter every 3,000–5,200 hours or when the pressure differential reaches 0.08–0.1MPa, whichever comes first.




• Lubricant: Use only Ingersoll Rand-approved lubricants to ensure optimal filter performance and prevent damage.




Consequences of Delayed Replacement

• Reduced Air Quality: Clogged filters allow oil mist and contaminants to pass through, leading to contaminated air that can damage downstream equipment (e.g., pneumatic tools, painting systems).




• Increased Energy Consumption: A dirty filter increases the pressure differential, forcing the compressor to work harder and consume more energy (up to 10% increase in energy costs).




• Compressor Damage: Excess oil and contaminants can cause wear on compressor components (e.g., bearings, seals), leading to costly repairs or premature failure.




• Production Downtime: Contaminated air can cause quality issues in downstream processes (e.g., paint defects, product contamination), resulting in production delays and lost revenue.




Summary

The 54509500 and 39890600 oil-gas separator filters are essential components for maintaining the performance and longevity of Ingersoll Rand M250 series compressors. Their high-efficiency filtration, durable construction, and compatibility with Ingersoll Rand systems make them a reliable choice for industrial applications. Regular maintenance and timely replacement are key to ensuring optimal performance and avoiding costly downtime.
