High-Performance Hydraulic & Transmission Filter Pair – Models 2901056612 & 2901164101

Two cartridge elements from the same 2901-series heavy-duty filter family, originally specified for transmission hydraulic and auxiliary steering circuits on large commercial vehicles, construction equipment, and stationary power units. 2901056612 is a glass-fiber return/pressure-guard cartridge for mid-size loops, while 2901164101 is a finer-grade element positioned as a pilot or secondary stage in the same circuit architecture. Both use wire-mesh-supported microglass media and are built for high-burst, high-cycle duty under continuous load.

Key Features

• 2901056612: Glass-fiber composite, 10–15 µm (β₁₀ ≥ 200), inside→out flow, epoxy-bonded end caps, nitrile O-ring standard




• 2901164101: Finer glass-fiber pack, 5–10 µm (β₅ ≥ 200), same housing footprint as 2901056612, suited to pilot/servo protection




• 304SS center tube (collapsed rated ≥ 30 bar), tin-plated CS outer cage




• Bypass optional per housing design; anti-drain-back not applicable (cartridge format)




• NBR seal standard; FKM available for high-temperature or ester-fluid estates




Technical Specifications

Application Guidance

2901056612 – Transmission hydraulic return or pump-guard on large commercial vehicles (12+ t class trucks, coach buses) and construction equipment with 2901-series filter heads. The 10–15 µm grade protects clutch-pack and valve-body circuits from pump-wear debris and tank-born contamination. Also deployable as a steering-return guard on the same chassis where the housing accepts the 95 mm OD cartridge.

2901164101 – Finer secondary / pilot stage in the same 2901-series housing family, or standalone pilot-loop filter on construction equipment with sensitive proportional valves. The 5–10 µm (β₅ ≥ 200) rating is tuned for servo spools where 10–15 µm chips cause stick-slip. Often paired upstream/downstream with a coarser 2901056612 in dual-cartridge heads, or used alone on lighter pilot-only circuits.

⚠️ Both are cartridges, not spin-ons — they seat into a reusable head/bowl. Confirm housing type (single vs. dual cartridge), bypass location (housing vs. element), and flow direction arrow before install. Do not substitute 2901164101 into a main-return first position without a coarser pre-filter ahead — it will blind rapidly in bulk-duty.

Fluid Compatibility

• ATF & transmission hydraulic oil (DEXRON, MERCON, ZF-lifeguard specs)




• Mineral hydraulic oil (ISO HM, HV)




• Biodegradable esters (HEES/HETG) – use FKM seals




• HFC water-glycol – NBR acceptable; FKM recommended




• Not for phosphate ester (HFDR) without seal/media confirmation




Installation & Service

1. Depressurize housing, open bowl/head, lift old cartridge by the center tube.




2. Inspect housing interior, O-ring groove, and bypass spring (if housed in bowl).




3. Seat new element — confirm flow arrow (Inside → Out typical) matches housing marking.




4. Torque bowl bolts evenly in cross pattern; do not over-compress the end-cap O-ring.




5. Bleed air at housing bleed port if fitted; check for leaks at operating pressure.




6. Replace per OEM transmission/hydraulic service interval (typical 2,000–3,000 h transmission / 1,000 h pilot) or when ΔP indicator signals.




Quality Assurance

• ISO 16889 – multi-pass β-ratio




• ISO 2941 – collapse resistance




• ISO 2942 – fabrication integrity (bubble point)




• ISO 2943 – media/fluid compatibility




• ISO 3968 – pressure drop vs. flow




Ordering

Quote 2901056612 (95×240 mm nom., 10–15 µm, transmission return/pilot-guard) or 2901164101 (95×220 mm nom., 5–10 µm, fine pilot/secondary) with seal material and quantity. Cross-reference to common 2901-series transmission hydraulic patterns available on request — provide your machine model, transmission type, and existing OEM number for confirmation.

All values nominal; 2901-series dimensions estimated from family pattern — confirm OD/length, housing type (bowl/head), and bypass design against your actual filter head before installation.
