Heavy-Duty Hydraulic Oil Filters – Models SH74120 & SH52359

These two filter elements share the same physical footprint (approx. 74 mm OD, 120 mm length for SH74120; 52 mm OD, 359 mm length for SH52359) but serve distinct roles in hydraulic circuits. SH74120 is a compact spin-on canister designed for pressure-line protection on small to mid-size mobile equipment, while SH52359 is a long, slim return-line element optimized for high dirt-holding capacity in confined housings. Both use glass-fiber composite media rated to ISO 16889 multi-pass testing, ensuring consistent β₁₀ ≥ 200 performance.

Key Features

• SH74120: spin-on configuration, integral bypass valve, anti-drain-back membrane prevents dry starts




• SH52359: inside-out flow, high-collapse center tube (≥ 40 bar), large dirt-holding volume for extended intervals




• NBR seals standard; FKM (Viton) available for high-temperature or ester-fluid applications




• Low initial pressure drop across the element, reducing parasitic energy loss




Technical Specifications

Application Guidance

SH74120 – Ideal for compact excavators, skid steer loaders, mini tractors, and agricultural implements where a spin-on filter provides quick service without tools. The 28 MPa working pressure allows placement directly after the pump discharge, protecting downstream valves and actuators. The anti-drain-back valve keeps the element wet during shutdown, reducing start-up wear.

SH52359 – Suited for larger return-line housings on wheel loaders, telescopic handlers, municipal sweepers, and industrial power units. Its 359 mm length provides generous dirt-holding capacity (up to 40+ grams typical) for extended change intervals in dirty environments. The high-collapse center tube withstands cold-start pressure spikes without imploding.

Installation Notes

• SH74120: Pre-fill with clean oil before threading on. Torque by hand plus ¾ turn; do not use a strap wrench on the canister. Replace when differential pressure reaches 2.5 bar or per OEM schedule.




• SH52359: Insert into the housing, ensuring the O-ring seals properly on both ends. Confirm flow direction (inside→out). Replace at 2.0–2.5 bar ΔP or when visual indicator signals clogging.




Fluid Compatibility

• Mineral oils (ISO HM, HV)




• Biodegradable esters (HEES, HETG) – use FKM seals




• Water-glycol (HFC) – confirm seal compatibility




• Not recommended for phosphate ester (HFDR) without specific approval




Quality Assurance

Each element is batch-tested to:

• ISO 16889 – Multi-pass filtration efficiency & dirt capacity




• ISO 2941 – Collapse/burst resistance




• ISO 3968 – Pressure drop versus flow




• ISO 2943 – Media/fluid compatibility




Ordering Information

Specify model number SH74120 or SH52359 together with desired micron rating (10, 20, or 25 µm), seal material (NBR or FKM), and bypass setting if different from standard. Cross-reference to common OEM part numbers is available upon request – provide your machine make and existing part number for assistance.

All values nominal; verify against actual system pressure, flow, and fluid type before installation.
