V7.0833-08 P2.0617-11 High Durability Hydraulic Filter V7.0833-08 P2.0617-11 Work Steadily Under Complex Working Conditions
Similar models
| V2-0920-08 L36 | P3.0520-01 | V3.0510-13 | V3.0520-06 |
| V2.1234-06 | P3.0730-52 | V3.0833-08 | V3.0520-08 |
| S2.0613-10 | P3.0720-62 | V3.0620-56 | V3.0520-13 |
| P2.0923-01 | P7.0820-11 | S2.0613-15 | V3.0520-18 |
| V3.0823-06 | V2.1460-26 | V3.0520-58 | V3.0520-53 |
| V3.0510-06 | V3.0510-08 | V3.0817-06 | V3.0520-56 |
| V3.0833-16 | P3.0510-11 | V3.0823-08 | V7.1460-07 V7146007 HY10393 SH52266 1035024892 |
| V3 0520-56 | V3092408 | P3.0823-01 | P3.0520-01K3 |
| V3 0510-56 | V0120 | AS150-01 | V3.0510-96 |
| V3.0520-16 | V3.0817-16 | AS100-01 | V7.0833-06 |
| V3.0934-08 | V2.1440-03 | AS010-00 | V2.0833-06 |
| V3.0730-56 | V3.0823-16 | V7.0833-08 | V3.0620-58 |
| V3.0617-08 | V3.0520-03 | P2.0617-11 | V2.1250-06 |
| S2.1234-00 |
Basic Info.
Type | Hydraulic oil filter | Material | Stainless steel wire mesh |
Warranty | 6 Month | Machinery Test Report | Provided |
Video Outgoing-Inspection | Provided | Place of Origin | Henan, China |
Brand Name | ALIPASTOR | Application | for Hydraulic system |
Product Name | Hydraulic oil filter | Part Number | V7.0833-08 P2.0617-11 |
Keyword | Hydraulic oil filter | Weight | Standard |
Filtration | 1-70micron | Color | Customize |
Filtration Grade | 99% | Warranty | 3 Months |
Production Capacity | 1000 PCS/Week |
Product Parameters
Model Number | V7.0833-08 P2.0617-11 |
Type | Hydraulic oil filter element |
Dimension | Standard |
Working Temperature | According to customer's request |
Work Pressure Different | Customized |
Material | Stainless steel wire mesh |
Filter Precision | 3~100μm |
Life span | 2000h |
MOQ | 1 pieces |
Lead Time | Around 5-7 days after order confirmed |
Package | PP bag inside, Inner carton, Export carton outside, or Wooden box as your requirement |
Shipping Method | By sea, by air, by express |
Filter Elements — Quick Reference (English)
Codes: V7.0833-08· P2.0617-11
Background: Both belong to the ARGO / ARGO‑HYTOS element numbering system (V‑series / P‑series).
Exact micron rating, media, bypass, collapse pressure, and seal are defined by the housing model + the element label/suffix, not by guessing from the digits.
1) V7.0833-08 — V‑Series (typical return‑line / in‑line element)
Field | Practical Info |
|---|---|
Series | V7.0833 — V7 size/family (larger tank‑top/inline canister, commonly ∅~98 × L~198 mm class in the ARGO ecosystem) |
Suffix -08 | Internal variant key → defines µm grade / media batch / seal compound for this size |
Typical media | Star‑folded glass‑fiber fleece (EXAPOR® type logic in later generations) — disposable, not wire‑mesh washable |
Flow direction | Outside → Inside (oil enters through pleats, exits via centre) |
Bypass / ΔP | Many V‑series housings/inserts carry a bypass ~3.0–3.5 bar near the inlet; confirm on your head nameplate |
Seal | NBR (black/grey) is std; FKM/Viton possible if your unit is spec’d for higher temp/phosphate ester |
What to read on‑site (30 seconds)
Housing head casting/nameplate: look for
V7.0833…+ bar rating + port size + flow arrowOld element end‑cap print: copy everythingfaintly stamped (often includes the real µ notation: e.g.
βx=cor10 µmstyle)
Procurement line (safe wording)
V7.0833-08 — ARGO-HYTOS V-series element (V7.0833 size) → Order against housing model stamped on HEAD (V7.0833…) → Confirm micron, media (glass-fiber), seal (NBR / FKM), and bypass option before accepting.2) P2.0617-11 — P‑Series (typical low‑pressure / return or suction‑side element)
Field | Practical Info |
|---|---|
Series | P2.0617 — P2 size/family (smaller flow class, often used as return filter cartridges or even suction guard positions depending on housing) |
Suffix -11 | Variant key (µm grade + seal + whether the cartridge itself includes a bypass disc) |
Typical media | Cellulose / wood‑pulp paper or composite (can also appear as stainless mesh in some cross‑ref stories) — P‑series is more “paper‑family” than V‑series glass‑fiber |
Bypass | Low‑pressure series often have a bypass valve in the housing/cartridge so the loop won’t starve if the element clogs |
Seal | Commonly NBR (丁腈) unless the nameplate calls out FKM |
What to read on‑site
Housing nameplate: should read something like P2.0617… + pressure rating (often ~10–16 bar range for return; suction versions are much lower) + port style
Old element: note if it feels like paper (matte, fibrous) vs mesh (metallic shine) and the O‑ring colour
Procurement line (safe wording)
P2.0617-11 — ARGO-HYTOS P-series element (P2.0617 size) → Issue only against housing stamped P2.0617… → Confirm micron rating, media type (paper/mesh), seal (NBR/FKM), and whether the design uses an element-integral bypass before buying.3) Quick Field ID (don’t mix them up)
Look at… | V7.0833-08 | P2.0617-11 |
|---|---|---|
Media feel/look | Usually glass‑fiber pleats (very uniform, “synthetic felt” look) | Usually paper/cellulose (wood‑pulp matte) or mesh variant |
Typical location | Bigger return can / tank‑top (flow arrow on head) | Smaller low‑pressure return or suction guard |
Seal colour | Black/grey = NBR · Brown/red = FKM | Black/grey = NBR · (rarely FKM unless nameplate says so) |
If you see… |
|
|
4) One‑Line BOM (copy‑paste)
V7.0833-08— ARGO‑HYTOS V‑series element, V7.0833 size; confirm µ + seal + bypass from head/element labelP2.0617-11— ARGO‑HYTOS P‑series element, P2.0617 size; confirm µ + media + seal + bypass from head/element label
📸 If you want these locked with µ and seal 100%:
Send 1) head nameplate photo (ports + stamped model + bar + arrow) and 2) old element upright next to a ruler (plus close‑up of end‑cap print). I’ll translate exactly what
-08/-11mean on yourmachines in the same clean sheet format.
Q2. Is customized filter or OEM available?
A: Yes,just offer your required sepcifications and drawings.
Q3. Can you produce according to the samples?
A: Yes,we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q4.What's the terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balancing.
Q5.What's your terms of delivery?
A: (1)FOB (2)CFR (3)CIF.
Q6. How about your delivery time?
A: Generally, under MOQ quantity take 5-7 working days after receiving your advance payment. The specific delivery time depends on models and the quantity of your order.
Q7. What's your sample policy?
A: We can supply the sample if we have stock, but the customers have to pay the sample cost and the courier cost at first, and we will refund sample cost in your next order.
