Hydraulic Oil Filter Elements – Models A910268 & A1348N

Two high-performance hydraulic and lubrication oil filter elements engineered for pressure-line, return-line, and bypass filtration across hydraulic power units, turbine lube systems, compressor oil circuits, and industrial machinery. A910268 is a direct interchangeable replacement element with a confirmed dimensional and performance envelope: 6.0" OD × 29.0" overall length, 4 µm absolute rating with β₄ = 1000, micro-glass media, double-open-end construction, 100 PSID collapse pressure, and Buna gasket . A1348N is the companion element in the same performance family — configurable to the host machine's housing envelope, micron requirement, and pressure class, built on the identical micro-glass architecture qualified to ISO 16889 multi-pass testing .

Key Features

• A910268: Confirmed 6.0" OD × 29.0" length, 4 µm / β₄ = 1000, SS/Teflon/micro-glass construction, double-open-end, 100 PSID collapse, Buna gasket, 8 lb




• A1348N: Configurable micro-glass or HV paper media, 1–25 µm selectable, β-ratio ≥ 1000, collapse pressure up to 210 bar




• Both: high dirt-holding capacity with optimized pleat geometry for low initial ΔP




• Gradient-density media structure for stable β-ratio throughout service life




• NBR seals standard; FKM optional for extended temperature range




• ISO 16889 multi-pass tested; ISO 2941 / 2942 / 2943 / 3968 validated




• Compatible with hydraulic fluid, machining fluids, lube oils, turbine & compressor oils, diesel, and synthetic lubricants




Technical Specifications

* A1348N dimensional envelope is configurable to the host housing — confirm OD, length, ID, and end-cap pattern against your existing element.

Application Guidance

A910268 – Installed in hydraulic power units, turbine lube oil systems, compressor oil circuits, and coalescer/separator housings where a 6.0" × 29.0" element with 4 µm absolute filtration is required. The β₄ = 1000 rating delivers 99.9 % capture efficiency at 4 µm — protecting precision components such as servo valves, proportional valves, and rolling-element bearings. The 100 PSID collapse rating and SS/Teflon/micro-glass construction suit both pressure-line and separator duties .

A1348N – A versatile hydraulic element for pressure-line, return-line, and bypass filtration across industrial and mobile equipment. The configurable micron grade (1 µm for servo-valve protection, 25 µm for coarse suction/pre-filtration) and collapse pressure class (up to 210 bar) let it be specified for pump-discharge protection, return-line filtration, compressor lube circulation, and turbine oil conditioning.

💡 Match the beta ratio, not just the micron number. A "10 µm" filter could be β₁₀ = 2 (50 % efficient) or β₁₀ = 200 (99.5 % efficient) — the performance difference is enormous . Always confirm both values when cross-referencing: A910268's β₄ = 1000 equals 99.9 % capture efficiency at 4 µm.

Fluid Compatibility

• Mineral hydraulic oil (ISO HM, HV)




• Mineral turbine / compressor / gear oil (lubrication duty)




• Synthetic lubricants and hydraulic fluids




• Diesel and other fuels




• Machining fluids




• Biodegradable esters (HEES, HETG) — use FKM seals




• HFC water-glycol — NBR acceptable; FKM recommended




• Phosphate ester (HFDR) — FKM seals + compatible media required




Installation & Service

1. Shut down the equipment and relieve system pressure to 0 bar; close the oil inlet valve.




2. Open the drain port at the bottom of the filter housing and the vent at the top; discharge the oil cleanly.




3. Withdraw the spent element by its center tube; clean all internal filter surfaces.




4. Inspect the housing interior, bypass spring (if fitted), and seal grooves.




5. Seat the new element — confirm flow direction arrow (Outside → Inside). Renew all O-rings / seals.




6. Close the housing, torque bolts evenly in cross pattern. Bleed air at the bleed port.




7. Restart and check for leaks at operating pressure.




8. Replace per clogging indicator (change-out typically at 25 PSID / ~1.7 bar ΔP for A910268-class elements) or 2000–2500 h service interval .




⚠️ When cross-referencing, confirm that dimensions, micron rating, β-ratio, collapse/burst pressure, bypass valve setting, and seal material all match the original — not just the part number. A properly matched replacement performs on par with the OEM element; a number-only match risks premature clogging or unfiltered bypass. Verify dimensions and connection type: even small differences in size can cause leaks or improper fitting .

Quality Assurance

• ISO 16889 – Multi-pass filtration performance (β-ratio, dirt capacity, ΔP)




• ISO 2941 – Collapse/burst resistance




• ISO 2942 – Manufacturing integrity (bubble point)




• ISO 2943 – Media/fluid compatibility




• ISO 3968 – Pressure drop vs. flow rate




• ISO 9001 – Quality management system certified manufacturing




Ordering

Specify A910268 (fixed: 6.0" × 29.0", 4 µm / β₄ = 1000, 100 PSID collapse, Buna, double-open-end) — direct interchange, guaranteed form-fit-function .

Specify A1348N with:

• Required micron rating (1 / 3 / 4 / 5 / 10 / 15 / 20 / 25 µm)




• Collapse pressure class (21 / 60 / 160 / 210 bar)




• Seal material (NBR / FKM)




• End-cap configuration (double / single open end)




• Mounting details (OD, length, ID, end-cap pattern of your current element)




Provide your existing element's dimensions or the host machine model and current OEM part number for cross-reference confirmation. Custom dimensions, media grades, and end-cap materials are available on request.

All values nominal; A910268 dimensions and performance are confirmed per its direct-interchange specification (6.0" OD × 29.0" length, 4 µm / β₄ = 1000, 100 PSID collapse, Buna gasket, SS/Teflon/micro-glass, double-open-end). A1348N dimensional envelope and pressure class are configurable per housing pattern — confirm against your current element or housing drawing before installation. Select micron grade to match circuit position: 3–5 µm for servo valves, 10 µm for piston pumps, 10–20 µm for vane/gear pumps, 20–25 µm for directional valves and cylinders.
