Heavy-Duty Spin-On Lube & Hyd-Aux Filter – Models C-1302 & C-1304

Two large-bore spin-on cartridges from the same heavy-duty filter family, originally specified as full-flow lube-oil elements on mid-to-large rotary screw compressors and diesel engines. C-1302 serves the M90-class compressor frame (118 mm OD × 283 mm, 1¾-12 UNF thread, 98/110 mm gasket), while C-1304 steps up to the 150S-class frame (135 mm OD × 302 mm, M38×1.5 thread, 100/110 mm gasket). A glass-fiber 10–15 µm hydraulic-aux variant of each is optionally offered for compressor-lube loops, gearbox return, or PTO-hydraulic guard on the same chassis.

Key Features

• C-1302: Cellulose media (lube std.), 20–25 µm nominal, 1¾-12 UNF thread, 98/110 mm square gasket, bypass + ADBV integrated




• C-1304: Cellulose media (lube std.), 20–25 µm nominal, M38×1.5 thread, 100/110 mm square gasket, taller 302 mm canister for higher dirt-holding




• Rolled carbon-steel shell, zinc-plated end caps, corrosion-resistant finish




• NBR gasket standard; FKM available for high-temperature or biodiesel/HVO duty




• Glass-fiber 10–15 µm / β₁₀ ≥ 200 hydraulic-aux variant available under same PN — specify media code when ordering




Technical Specifications

Application Guidance

C-1302 – Full-flow lube on M90-class rotary screw compressors and mid-size diesel engines used in industrial plants, workshops, and generator sets. The 1¾-12 UNF head and 283 mm length suit 500+ hour drain intervals under continuous load. Also deployable as hydraulic-aux (gearbox return, compressor-lube loop) in glass-fiber variant on the same skid.

C-1304 – Full-flow lube on 150S-class compressors (larger displacement, ~110 kW class) and heavy-duty diesels on mining/quarry equipment. The 135 mm OD × 302 mm canister and M38×1.5 large-bore head deliver extended dirt-holding — two per V-configuration typical on large compressor packages. Hyd-aux glass-fiber variant suits main return-guard or cooler-loop duty on the same power pack.

📎 Thread difference is critical: C-1302 = 1¾-12 UNF (98/110 gasket), C-1304 = M38×1.5 (100/110 gasket) — not head-interchangeable. Confirm your filter head thread and gasket face before ordering; the 150S head is a larger-diameter pad than M90.

Fluid Compatibility

• Mineral compressor oil (ISO VG 32/46/68) – cellulose lube versions




• Mineral hydraulic oil (ISO HM/HV) – glass-fiber hyd-aux variant




• Synthetic compressor lubricant – FKM seals recommended




• HFC water-glycol – NBR acceptable; FKM recommended




• Not for phosphate ester (HFDR) without seal upgrade




Installation & Service

1. Clean filter head face; inspect center tube, threads, and gasket groove.




2. Lubricate gasket with clean oil, spin on by hand until seated + ¾ turn. No strap wrench on the canister — the large shell dents easily.




3. Pre-fill if head design allows; run unit to operating temperature and check for leaks at pressure.




4. For compressor lube duty: first change at 500 h, then every 2000 h or 6 months. For hyd-aux: replace when ΔP reaches 2.5 bar or per loop schedule.




5. Log hours — shorten interval in high-dust or high-moisture environments.




Quality Assurance

• SAE J1858 / ISO 4548 – efficiency & capacity




• ISO 2941 – collapse (hyd-aux cage, glass-fiber variant)




• ISO 2943 – media/fluid compatibility




• Shell burst test per batch




Ordering

Quote C-1302 (118×283 mm, 1¾-12 UNF, 98/110 gasket, M90-class) or C-1304 (135×302 mm, M38×1.5, 100/110 gasket, 150S-class) with duty (cellulose lube / glass-fiber hyd-aux), micron, and seal choice. Cross to common heavy-duty lube-spin-on patterns (including the AO1302/AO1304 compressor references in the same family) available on request — provide machine model and existing OEM number for confirmation.

All values nominal; confirm thread (1¾-12 UNF vs. M38×1.5), gasket (98/110 vs. 100/110), and head pressure class against your actual filter head before installation.
