MKO-1820-Y Air Filter Element: Comprehensive Guide to Performance, Applications Maintenance

Technical Specifications

• Model: MKO-1820-Y




• Filter Media: Resin-treated microporous filter paper + sodium borosilicate glass fiber







• Filtration Efficiency: 99.998% for particles ≥0.01µm (ISO 8573.1-2010 standard)




• Working Pressure: -21~210 bar




• Temperature Range: -10°C to +100°C




• Dimensions: 76.0 mm (Diameter) × 648 mm (Height)




• Certifications: ISO 9001, CE




• Flow Rate: 180 m³/h

•




Key Features

1. High-Precision Filtration

• Removes 99.998% of particles ≥0.01µm, including oil aerosols and solid contaminants

  .







• Multi-layer media (glass fiber + activated carbon) ensures efficient separation of oil and water

  .







2. Durability in Harsh Conditions

• Stainless steel support mesh and anti-corrosion end caps withstand temperatures from -20°C to +240°C

  .







• Resistant to chemical corrosion and mechanical wear.




3. Low Maintenance & Cost-Effective

• Replaceable cartridge design simplifies maintenance

  .







• Extended service life of 6,000–8,000 hours under standard operating conditions

  .







4. Easy Installation

• Standardized thread design ensures compatibility with most compressed air systems

  .







• Includes color-coded top caps for quick grade identification.

•




Applications

• Industrial Machinery: Protects pneumatic tools, compressors, and valves from contaminants

  .







• Food & Beverage: Maintains hygiene standards by filtering airborne particles in production lines

  .







• Pharmaceuticals: Ensures ISO-clean air for sensitive manufacturing processes

  .







• Oil & Gas: Removes moisture and particulates in pipeline systems

  .







Installation Guide

1. Drain the System: Release pressure and drain residual oil/water

   .







2. Locate the Filter Housing: Typically near the compressor or main pipeline

   .







3. Replace the Filter:

   • Use a wrench to remove the old element.




   • Install MKO-1820-Y with a hand-tight + ¼ turn

     .










4. Test the System: Monitor pressure drop (should be ≤80 mbar dry, ≤190 mbar wet)

   .







Pro Tip: Pair with a coalescing filter for optimal moisture removal .

Maintenance Tips

• Replacement Interval: Every 6–8 months or 6,000–8,000 operating hours

  .







• Pressure Monitoring: Sudden drops indicate clogging or media degradation

  .







• Disposal: Recycle used elements at certified facilities

  .







FAQ

Q1: Compatible with non-Mikropor systems?

A: Yes, designed for universal use in compressed air pipelines

Q2: Max flow rate?

A: 180 m³/h at 7 bar pressure

Q3: How to check filter condition?

A: Use differential pressure gauges or visual inspection for media discoloration

Why Choose MKO-1820-Y?

• ISO-Certified Quality: Meets global standards for compressed air filtration

  .







• Cost Savings: Reduces energy consumption by maintaining optimal airflow

  .







• Global Availability: Supplied by trusted manufacturers like alipastor

  .
